Raymarine SeaTalkNG Auxiliary Alarm Buzzer

Description

Auxillary Alarm Buzzer by Raymarine. Raymarine's SeaTalkng Auxiliary Alarm Buzzer is a network accessory that repeats alarm and alert tones from compatible network-connected devices, ensuring audible alarms are heard above and below deck. This product is made of high-quality materials to serve you for years to come. Designed using state-of-the-art technology and with customers in mind. It will meet your needs and deliver great quality at an affordable cost.

Features

• Powerful 100 dBm alarm buzzer
• Repeats alarms and notifications from SeaTalkng and NMEA2000 compatible instruments, AIS receivers, autopilots, and engine systems
• Compact, waterproof module repeats network alarms to ensure they are heard over the noise of engines, wind, weather, entertainment and more
• Simple SeaTalkng network interfacing for power and connectivity. No setup required
• Waterproof to IPx6 and IPx7 standards and can be used above or below decks
• Multiple alarms modules can be fitted to expand the coverage on large vessels as needed

Specifications

• Nominal Supply Voltage: 12 VDC(Supplied by SeaTalkng)
• Operating Voltage Range: 9VDC to 16VDC (protected upto 32VDC)
• Power Consumption: 25mA At nominal supply voltage
• Sound Pressure Level(SPL) of Audible Alarm: >85dB(A)at a distance of 1 meter
• Environmental: Operating Temperature: -20°C to +55°C (-4°F to 131°F)
• Storage Temperature: -30°C to +70°C (-22°F to 158°F)
• Relative Humidity: max 93%
• Waterproof to IPx6 and IPx7
• Supported Connection Protocols: SeaTalkng /NMEA2000 (via Devicenet adaptor)
• LEN (refer to SeaTalkng Reference manual for more information): 1
